Chapter 13 413
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:SENS{1-4}:CORR:TYPE{1-4}?
Syntax :SENSe{[1]|2|3|4}:CORRection:TYPE{[1]|2|3|4}?
Description For trace 1 (:TYPE1) to trace 4 (:TYPE4) of channel 1 (:SENS1) to channel 4 (:SENS4),
reads out the information (calibration type, port numbers) of the applied calibration
coefficients for the actual error correction.
Query response {ERES|NONE|RESPO|RESPS|RESPT|SOLT1|SOLT2},{numeric 1},{numeric
2}<newline><^END>
{ERES|NONE|RESPO|RESPS|RESPT|SOLT1|SOLT2}:
{numeric 1}: the calibration port number
(This parameter is 0 when the first parameter is NONE.)
{numeric 2}: the calibration port number
(This parameter is 0 when the first parameter is not ERES, RESPT and
SOLT2.)
Example of use
10 OUTPUT 717;":SENS1:CORR:TYPE1?"
20 ENTER 717;A$
Equivalent key No equivalent key is available on the front panel.
Description
ERES The enhanced response calibration is applied.
NONE Any calibration is not applied.
RESPO The response calibration (open) is applied.
RESPS The response calibration (short) is applied.
RESPT The response calibration (thru) is applied.
SOLT1 The full 1-port calibration is applied.
SOLT2 The full 2-port calibration is applied.
