360 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:MMEM:STOR:RLIM
Syntax :MMEMory:STORe:RLIMit <string>
Description Saves the ripple limit table of the active trace (specified with the
:CALC{1-4}:PAR{1-4}:SEL command) of the active channel (specified with the
:DISP:WIND{1-4}:ACT command) into a file in the CSV format.
Specify the file name with the .sta extension. If you want to specify a file on the floppy
disk drive, you need to add “A:” at the beginning of the file name. When you write
directory names and the file name, separate them with a “/” (slash) or “\” (backslash).
Note that if a file with the specified file name already exists, its contents will be
overwritten. (No query)
Parameters
Example of use
10 OUTPUT 717;":MMEM:STOR:RLIM ""RTest1/Rlim01.csv"""
10 OUTPUT 717;":MMEM:STOR:RLIM ""A:Rlim01.csv"""
Related commands :MMEM:LOAD:RLIM on page 350
:DISP:WIND{1-4}:ACT on page 318
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Analysis] - Ripple Limit - Edit Ripple Limit - Export to CSV File
<string>
Description File name used to save the ripple limit table.
Range 254 characters or less
