:DISP:WIND{1-4}:TRAC{1-4}:Y:RLEV
Syntax :DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:RLEVel <numeric>
:DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:RLEVel?
Description For trace 1 (:TRAC1) to trace 4 (:TRAC4) of channel 1 (:WIND1) to channel 4 (:WIND4),
sets the value of the reference graticule line.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:WIND1:TRAC1:Y:RLEV 1E2"
20 OUTPUT 717;":DISP:WIND1:TRAC1:Y:RLEV?"
30 ENTER 717;A
Related commands :DISP:WIND{1-4}:Y:DIV on page 336
:DISP:WIND{1-4}:TRAC{1-4}:Y:PDIV on page 330
:DISP:WIND{1-4}:TRAC{1-4}:Y:RPOS on page 332
Equivalent key
[Scale] - Reference Value
<numeric>
Description Value of reference graticule line
Range -5E8 to 5E8
Preset value
0
*1
Unit Varies depending on the data format as follows:
Logarithmic Magnitude: dB (decibel)
Phase, Expand Phase, Positive Phase: ° (degree)
Group Delay: s (second)
Others: No unit
*1.When the data format is “SWR,” the preset value is 1.
