330 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:DISP:WIND{1-4}:TRAC{1-4}:Y:PDIV
Syntax :DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:PDIVision <numeric>
:DISPlay:WINDow{[1]|2|3|4}:TRACe{[1]|2|3|4} :Y[:SCALe]:PDIVision?
Description For trace 1 (:TRAC1) to trace 4 (:TRAC4) of channel 1 (:WIND1) to channel 4 (:WIND4):
when the data format is not the Smith chart format or the polar format, sets the scale per
division; when the data format is the Smith chart format or the polar format, sets the full
scale value (the value of the outermost circle).
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:WIND1:TRAC1:Y:PDIV 2.5"
20 OUTPUT 717;":DISP:WIND1:TRAC1:Y:PDIV?"
30 ENTER 717;A
Related commands :DISP:WIND{1-4}:Y:DIV on page 336
:DISP:WIND{1-4}:TRAC{1-4}:Y:RLEV on page 331
:DISP:WIND{1-4}:TRAC{1-4}:Y:RPOS on page 332
Equivalent key
[Scale] - Scale/Div
<numeric>
Description Scale value
Range 1E-18 to 1E8
Preset value Varies depending on the data format as follows:
Logarithmic Magnitude: 10
Phase, Expand Phase, Positive Phase: 90
Group Delay: 1E-8
Smith, Polar, SWR: 1
Linear Magnitude: 0.1
Real, Imaginary: 0.2
Unit Varies depending on the data format as follows:
Logarithmic Magnitude: dB (decibel)
Phase, Expand Phase, Positive Phase: ° (degree)
Group Delay: s (second)
Others: No unit
