314 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:DISP:MAX
Syntax :DISPlay:MAXimize {ON|OFF|1|0}
:DISPlay:MAXimize?
Description Turns ON/OFF the window maximization of the active channel (specified with the
:DISP:WIND{1-4}:ACT command).
If you turned ON the maximization, only the window of the active channel is maximized
on the LCD display and the windows of the other channels are not displayed.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:MAX ON"
20 OUTPUT 717;":DISP:MAX?"
30 ENTER 717;A
Related commands :DISP:WIND{1-4}:ACT on page 318
Equivalent key
[Channel Max]
:DISP:SKEY
Syntax :DISPlay:SKEY[:STATe] {ON|OFF|1|0}
:DISPlay:SKEY[:STATe]?
Description Turns ON/OFF the display of the softkey labels.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:MAX ON"
20 OUTPUT 717;":DISP:MAX?"
30 ENTER 717;A
Equivalent key [Entry Off] ([Softkey On/Off])
Description
ON or 1 Turns ON the maximization.
OFF or 0 (preset value) Turns OFF the maximization.
Description
ON or 1 (preset value) Specifies ON.
OFF or 0 Specifies OFF.
