Chapter 13 313
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:DISP:FSIG
Syntax :DISPlay:FSIGn {ON|OFF|1|0}
:DISPlay:FSIGn?
Description Turns on or off the Fail display when the limit test fails.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:FSIG OFF"
20 OUTPUT 717;":DISP:FSIG?"
30 ENTER 717;A
Related commands :CALC{1-4}:LIM on page 232
Equivalent key
[Analysis] - Limit Test - Fail Sign
:DISP:IMAG
Syntax :DISPlay:IMAGe {NORMal|INVert}
:DISPlay:IMAGe?
Description Selects the display type of the LCD display.
Parameters
Query response {NORM|INV}<newline><^END>
Example of use
10 OUTPUT 717;":DISP:IMAG INV"
20 OUTPUT 717;":DISP:IMAG?"
30 ENTER 717;A$
Equivalent key [Display] - Invert Color
Description
ON or 1 (preset value) Turns on the Fail display.
OFF or 0 Turns off the Fail display.
Description
NORMal
(preset value)
Specifies the normal display (background color: black).
INVert Specifies the display in which the color of the normal display is
inverted (background color: white).
