:CALC{1-4}:MATH:FUNC
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MATH:FUNCtion {NORMal|
SUBTract|DIVide|ADD|MULTiply}
:CALCulate{[1]|2|3|4}[:SELected]:MATH:FUNCtion?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), selects the data trace display method (math
method between measurement data and memory trace data).
The math result according to this setting is displayed on the data trace.
Parameters
Where Data is the measurement data and Mem is the data stored in the memory trace.
Query response {NORM|DIV|MULT|SUBT|ADD}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MATH:FUNC DIV"
20 OUTPUT 717;":CALC1:MATH:FUNC?"
30 ENTER 717;A$
Related commands :CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Display] - Data Math - OFF|Data / Mem|Data * Mem|Data − Mem|Data + Mem
:CALC{1-4}:MATH:MEM
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MATH:MEMorize
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), copies the measurement data at the execution of
the command to the memory trace. (No query)
Example of use
10 OUTPUT 717;":CALC1:MATH:MEM"
Related commands :CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Display] - Data −> Mem
Description
NORMal (preset
value)
Specifies Data (no math).
DIVide Specifies Data / Mem.
MULTiply Specifies Data × Mem.
SUBTract Specifies Data - Mem.
ADD Specifies Data + Mem.
