Chapter 13 277
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:CALC{1-4}:MARK{1-10}:NOTC:THR
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:NOTCh:THReshold
<value>
:CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:NOTCh:THReshold?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), sets the notch definition value of marker 1
(:MARK1) to marker 9 (:MARK9) and reference marker (:MARK10).
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {value}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:NOTC:THR 5"
20 OUTPUT 717;":CALC1:MARK1:NOTC:THR?"
30 ENTER 717;A
Related commands :CALC{1-4}:PAR{1-4}:SEL on page 286
:CALC{1-4}:MARK:NOTC on page 261
:CALC{1-4}:MARK{1-10}:NOTC:DATA? on page 276
Equivalent key
[Marker Search] - Notch Value
<value>
Description Notch definition value
Range -5E8 to 5E8
Preset value -3
Unit Varies depending on the data format as follows:Amplitude
(MLOG): dB (decibel)
Phase (PHAS), expanded phase (UPH), positive phase (PPH): °
(degree)
Group delay (GDEL): s (second)
Others: No unit
