276 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:MARK{1-10}:NOTC:DATA?
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer{[1]|2|3|4|5|6|7|8|9|10}:NOTCh:DATA?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), reads out the notch search result of marker 1
(:MARK1) to marker 9 (:MARK9) and reference marker (:MARK10).
If the notch search is impossible, an error occurs and the command is ignored.
In this case, no query response is obtained. (Query only)
Query response {value 1},{value 2},{value 3},{value 4}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:NOTC:DATA?"
20 ENTER 717;A,B,C,D
Related commands :CALC{1-4}:PAR{1-4}:SEL on page 286
:CALC{1-4}:MARK:NOTC on page 261
:CALC{1-4}:MARK{1-10}:NOTC:THR on page 277
Equivalent key No equivalent key is available on the front panel.
Description
{value 1} Bandwidth.
{value 2} Center frequency.
{value 3} Q value.
{value 4} Loss.
