254 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:MARK:FUNC:MULT:TYPE
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer:FUNCtion:MULTi:
:TYPE {MAXimum| MINimum|PEAK|LPEak|RPEak|TARGet|LTARget|RTARget}
:CALCulate{[1]|2|3|4}[:SELected]:MARKer:FUNCtion: MULTi
:TYPE?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), selects and turns on the multi search type.
Parameters
Query response {OFF|PEAK|TARG}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:FUNC:MULT:TYPE PEAK"
20 OUTPUT 717;":CALC1:MARK1:FUNC:MULT:TYPE?"
30 ENTER 717;A$
Related commands :CALC{1-4}:MARK:FUNC:MULT:PEXC on page 249
:CALC{1-4}:MARK:FUNC:MULT:PPOL on page 250
:CALC{1-4}:MARK:FUNC:MULT:TARG on page 251
:CALC{1-4}:MARK:FUNC:MULT:TRAC on page 252
:CALC{1-4}:MARK:FUNC:MULT:TTR on page 253
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Marker Search] - Multi Peak - Search Multi Peak
[Marker Search] - Multi Target - Search Multi Target|
Description
OFF Turn off the multi search mode
PEAK Turn on the multi peak search
TARGet Turn on the multi target search
