252 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:MARK:FUNC:MULT:TRAC
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer:FUNCtion: MULTi: TRACking
{ON|OFF|1|0}
:CALCulate{[1]|2|3|4}[:SELected]:MARKer:FUNCtion: MULTi: TRACking?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), turns ON/OFF the search tracking (function to
repeat the search for each sweep) of the multi target or peak search.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK1:FUNC:MULT:TRAC ON"
20 OUTPUT 717;":CALC1:MARK1:FUNC:MULT:TRAC?"
30 ENTER 717;A
Related commands :CALC{1-4}:MARK:FUNC:MULT:TYPE on page 254
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key
[Marker Search] - Tracking
Description
ON or 1 Turns ON the search tracking.
OFF or 0 (preset value) Turns OFF the search tracking.
