244 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:MARK:COUP
Syntax :CALCulate{[1]|2|3|4}[:SELected]:MARKer:COUPle {ON|OFF|1|0}
:CALCulate{[1]|2|3|4}[:SELected]:MARKer:COUPle?
Description For channel 1 (:CALC1) to channel 4 (:CALC4), turns ON/OFF the marker coupling
between traces.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:MARK:COUP OFF"
20 OUTPUT 717;":CALC1:MARK:COUP?"
30 ENTER 717;A
Equivalent key [Marker Fctn] - Couple
Description
ON or 1 (preset value) Turns ON the marker coupling.
OFF or 0 Turns OFF the marker coupling.
