240 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:LIM:OFFS:STIM
Syntax :CALCulate{[1]|2|3|4}[:SELected]:LIMit:OFFSet:STIMulus <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:LIMit:OFFSet:STIMulus?
Description For channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), sets the stimulus offset of the limit line.
The setting of the limit line doesn't change even if the offset value is changed.
Parameters
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:LIM:OFFS:STIM 5E3"
20 OUTPUT 717;":CALC1:LIM:OFFS:STIM?"
30 ENTER 717;A
Related commands :CALC{1-4}:LIM on page 232
:CALC{1-4}:LIM:OFFS:AMPL on page 238
:CALC{1-4}:LIM:OFFS:MARK on page 239
Equivalent key
[Analysis] - Limit Test - Limit Line Offsets - Stimulus Offset
<numeric>
Description The stimulus offset value of the limit line.
Range -1E12 to 1E12
Preset value 0
Unit Hz (hertz), dBm or second
