228 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:CALC{1-4}:FUNC:PPOL
Syntax :CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:PPOLarity {POSitive|
NEGative|BOTH}
:CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:PPOLarity?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), selects the polarity when performing the peak
search with the :CALC{1-4}:FUNC:EXEC command.
Parameters
Query response {POS|NEG|BOTH}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:FUNC:PPOL BOTH"
20 OUTPUT 717;":CALC1:FUNC:PPOL?"
30 ENTER 717;A$
Related commands :CALC{1-4}:FUNC:EXEC on page 225
:CALC{1-4}:FUNC:PEXC on page 226
:CALC{1-4}:FUNC:TYPE on page 231
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key No equivalent key is available on the front panel.
Description
POSitive (preset value) Specifies the positive peak.
NEGative Specifies the negative peak.
BOTH Specifies both the positive peak and the negative peak.
