E5061A/E5062A commands
:CALC{1-4}:FUNC:PEXC
Syntax :CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:PEXCursion <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:PEXCursion?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), sets the lower limit for the peak excursion value
when executing the peak search with the :CALC{1-4}:FUNC:EXEC command.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:FUNC:PEXC 0.2"
20 OUTPUT 717;":CALC1:FUNC:PEXC?"
30 ENTER 717;A
Related commands :CALC{1-4}:FUNC:EXEC on page 225
:CALC{1-4}:FUNC:PPOL on page 228
:CALC{1-4}:FUNC:TYPE on page 231
:CALC{1-4}:PAR{1-4}:SEL on page 286
Equivalent key No equivalent key is available on the front panel.
<numeric>
Description Lower limit for the peak excursion value
Range 0 to 5e8
Preset value 3
Unit Varies depending on the data format as follows:
Logarithmic Magnitude: dB (decibel)
Phase, Expand Phase, Positive Phase: ° (degree)
Group Delay: s (second)
Others: No unit
