Chapter 13 207
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:CALC{1-4}:BLIM:FAIL?
Syntax :CALCulate{[1]|2|3|4}[:SELected]:BLIMit:FAIL?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4) (specified with the
:CALC{1-4}:PAR{1-4}:SEL command), reads out the bandwidth test result. (Query only)
Query response {1|0}<newline><^END>
When the bandwidth limit test is set to OFF, 0 is always read out.
Example of use
10 OUTPUT 717;":CALC1:BLIM:FAIL?"
20 ENTER 717;A
Related commands :CALC{1-4}:PAR{1-4}:SEL on page 286
:CALC{1-4}:BLIM on page 203
Equivalent key No equivalent key is available on the front panel.
Description
1 The bandwidth test result is FAIL.
0 The bandwidth test result is PASS.
