Chapter 13 201
SCPI Command Reference
IEEE Common Commands
13. SCPI Command
Reference
*STB?
Syntax *STB?
Description Reads out the value of the Status Byte Register. (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;"*STB?"
20 ENTER 717;A
Equivalent key No equivalent key is available on the front panel.
*TRG
Syntax *TRG
Description If the trigger source is set to GPIB/LAN (set to BUS with the :TRIG:SOUR command),
triggers the E5061A/E5062A waiting for a trigger. (No query)
Example of use
10 OUTPUT 717;"*TRG"
Related commands :TRIG:SOUR on page 485
Equivalent key No equivalent key is available on the front panel.
*WAI
Syntax *WAI
Description Waits for the execution of all commands sent before this command to be completed. (No
query)
Example of use
10 OUTPUT 717;"*WAI"
Equivalent key No equivalent key is available on the front panel.
