200 Chapter 13
SCPI Command Reference
IEEE Common Commands
*SRE
Syntax *SRE <numeric>
*SRE?
Description Sets the value of the Service Request Enable Register.
Parameters
If the specified parameter is out of the allowable setup range, the result of bitwise AND
with 255 (0xff) is set. Note that bit 6 cannot be set to 1.
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;"*SRE 128"
20 OUTPUT 717;"*SRE?"
30 ENTER 717;A
Related commands *ESE on page 197
:STAT:OPER:ENAB on page 442
:STAT:QUES:ENAB on page 454
Equivalent key No equivalent key is available on the front panel.
<numeric>
Description Setup value of the register
Range 0 to 255
Preset value 0
Resolution 1
