Operation and Features 2
Remote Interface Configuration
E3632A User’s Guide 55
4 Save the change and choose the parity.
NONE 8 BITS
The power supply is configured for 8 data bits with no
parity when shipped from the factory. Choose from one of
the following by turning the knob to the right or left:
None 8 Bits, Odd 7 Bits, or Even 7 Bits. When you set
parity, you are indirectly setting the number of the data
bits.
5 Save the change and turn off the I/O configuration mode.
CHANGE SAVED
The RS- 232 baud rate and parity selections are stored in
non- volatile memory, and does not change when power
has been off or after a remote interface reset. The power
supply displays a message to show that the change is now
in effect. If the baud rate and the parity are not changed,
NO CHANGE will be displayed for one second.
I/O Config
I/O Config
NOTE
To exit the I/O configuration mode without any further changes, press
until the NO CHANGE message is displayed.
I/O Config
