2 Operation and Features
Remote Interface Configuration
54 E3632A User’s Guide
4 Save the change and turn off the I/O configuration mode.
CHANGE SAVED
The address is stored in non- volatile memory, and does
not change when power has been off or after a remote
interface reset. The power supply displays a message to
show that the change is now in effect. If the GPIB address
is not changed, NO CHANGE will be displayed for one
second.
To set the baud rate and parity (RS-232)
To configure the power supply for the RS- 232 interface,
proceed as follows:
1 Turn on the remote configuration mode.
HPIB/488
You will see the above message on the display if the
power supply has not been changed from the
factory- setting.
Notice that if you changed the remote interface selection
to RS- 232 before, RS-232 message will be displayed.
2 Choose the RS- 232 interface.
RS-232
You can choose the RS- 232 interface by turning the knob
to the left.
3 Move to the RS- 232 interface setting mode and select the
baud rate.
9600 BAUD
The rate is set to 9600 baud when the power supply is
shipped from the factory. Choose from one of the
following by turning the knob to the right or left: 300,
600, 1200, 2400, 4800, or 9600 baud.
I/O Config
NOTE
To exit the I/O configuration mode without any further changes, press
until the NO CHANGE message is displayed.
I/O Config
I/O Config
I/O Config
