Getting Started 1
Product at a Glance
E3632A User’s Guide 23
ERROR Hardware or remote interface command errors are detected and the error bit has not been cleared.
OFF The output of the power supply is disabled. Refer to “System-Related Operations” on page 46 for more
information.
Unreg The output of the power supply is unregulated (output is neither CV nor CC).
CV The power supply is in the constant voltage mode.
CC The power supply is in the constant current mode.
Table 1 - 5 Display annunciators overview (continued)
Item Description
NOTE
To review the display annunciators, hold down as you
turn on the power supply.
Display Limit
