Characteristics and Specifications 7
Environmental Characteristics
E3632A User’s Guide 169
Environmental Characteristics
Refer to “Environmental Conditions” on page VI
Electrical Specifications
Table 7 - 2 Electrical specifications
Voltage output (V)
(at 0 °C to 40 °C)
Low range 0 V to +15 V
High range 0 V to +30 V
Current output (A)
(at 0 °C to 40 °C)
Low range 0 A to 7 A
High range 0 A to 4 A
Programming accuracy
[1]
12 months (at 25 °C ±5 °C,
±(% of output + offset)
Voltage 0.05% + 10 mV
Current 0.2% + 10 mA
Readback accuracy
[1]
12 months (over GPIB and RS-232
or front panel with respect to the
actual output at 25 °C ±5 °C), ±(%
of output + offset)
Voltage 0.05% + 5 mV
Current 0.15% + 5 mA
Ripple and noise
(with outputs ungrounded, or with
either output terminal grounded,
20 Hz to 20 MHz)
Normal mode
voltage
<0.35 mVrms and 2 mVpp
Normal mode
current
<2 mArms
Common mode
current
<1.5 μArms
Load regulation
±(% of output + offset)
(Change in output voltage or
current for any load change within
ratings with remote sensing
connected)
Voltage <0.01% + 2 mV
Current <0.01% + 250 μA
