Using the Tracking Generator
228
Repeater System Effective Sensitivity Measurement
Description
This procedure is used to measure the effective sensitivity of a repeater system
using the Spectrum Analyzer/Tracking Generator option. Once effective
sensitivity measured, receiver sensitivity degradation is calculated.
