User's Manual

SSB Receivers
181
On the Radio set the Receiver’s Controls as follows:
21. Decrease the Receiver’s volume control until the AC Level meter reads
−6 dB.
On the Test Set using the knob and data entry keys:
22. Decrease Amplitude until the SINAD meter reads 12 dB.
Sensitivity (at 12dB SINAD) is displayed on the screen as Amplitude as
shown.
❒ If desired, use the meter averaging function for the SINAD indicator.
a. Select dB on the SINAD meter.
b. Press the AVG key.
❒ If desired, select the number of readings to average.
• Enter the number of readings to average.
Higher number of readings averaged will require longer to
reach the final indication.
Sensitivity
To Screen
RX TEST
AC Level
Filter 1
50Hz HPF
Filter 2
15kHz HPF
Atten Hold
On/Off
Ext Load R
8.00
Ω
RF GEN
RF ANL
AF ANL
SCOPE
SPEC ANL
ENCODER
DECODER
RADIO INT
More
dB
dB
-33.12
SINAD
RF Gen Freq
28.310700
MHz
Amplitude
0.178
uV
Output Port
RF Out/Dupl
AFGen1 Freq
1.0000
kHz
AFGen2 Freq
1.0000
kHz
AFGen2 To
Off
FM
012.57
Avg
24
Ref
AFGen1 To
Off
FM
