FM Receivers
101
FM CDCSS Sensitivity Measurement
Description
This procedure is used to measure an FM Receiver’s Continuous
Digital Coded Squelch System (CTCSS) sensitivity. The minimum
signal input at the Receiver’s antenna (modulated with digital code) that
opens the squelch is measured and displayed. Squelch hysteresis is also
measured and calculated.
