Chapter 2: Task Guide
Using Symbols
Using Symbols
You can use symbol names in place of data values when:
• Setting up triggers
• Displaying captured data
• Searching for patterns in Listing displays
• Setting up pattern filters
• Setting up ranges in the System Performance Analyzer
Symbol names can be: variable names, procedure names, function
names, source file line numbers, etc.
You can load symbol name definitions into the logic analyzer from a
program's object file or from a general-purpose ASCII format symbol
file, or you can define symbol names in the logic analyzer.
• “To load object file symbols” on page 96
• “To adjust symbol values for relocated code” on page 97
• “To create user-defined symbols” on page 98
• “To enter symbolic label values” on page 99
• “To create an ASCII symbol file” on page 100
• “To create a readers.ini file” on page 101
See Also To go to a pattern in the Listing (see the Listing Display Tool help
volume)
To modify the Source Viewer trace setup (see the Listing Display Tool
help volume)
To define System Performance Analyzer state interval ranges (see the
System Performance Analyzer help volume)
