Chapter 2: Task Guide
To select transitional timing or store qualified
To specify which analyzer has Timing Zoom
NOTE: If you have both analyzers of the module turned on, you need to specify which
analyzer you want to use Timing Zoom with.
1. In the Sampling tab, select the Timing Zoom button.
2. In the Timing Zoom controls dialog, select the analyzer that Timing Zoom
will work with.
To set the Timing Zoom sample period
If you want to see more or less sampling resolution around the trigger,
you can adjust the Timing Zoom sample period.
1. In the Sampling tab, select the Timing Zoom button.
2. In the Timing Zoom controls dialog, select the sample period.
