186
Chapter 3: Reference
Specifications and Characteristics
Specifications and Characteristics
NOTE: For a complete comparison of all logic analyzer specifications and
characteristics refer to the "Agilent Technologies 16700 Series Logic Analysis
System Product Overview".
• “Agilent 16750A/B Logic Analyzer Specifications” on page 186
• “Agilent 16750A/B Logic Analyzer Characteristics” on page 186
• “What is a Specification?” on page 189
• “What is a Characteristic?” on page 189
Agilent 16750A/B Logic Analyzer Specifications
The specifications are the performance standards against which the
product is tested. These specifications apply only to the Agilent
Technologies 16750A/B 400 MHz State/2 GHz Timing Zoom logic
analyzer:
Maximum State Clock Speed: 400 MHz
Threshold Accuracy: +/-(65 mV + 1.5% of threshold setting)
Minimum Master-to-Master Clock Time: 5.0 ns at 200 MHz
2.5 ns at 400 MHz
Setup/Hold Time:
*Single Clock, Single Edge: 4.5/-2.0 ns through -2.0/4.5 ns,
adjustable in 100-ps increments
*Multiple Edges: 5.0/-2.0 ns through -1.5/4.5 ns,
adjustable in 100-ps increments
* Specified for an input signal VH=-0.9 V, VL=-1.7 V, threshold=-1.3 V,
slew rate=1 V/ns
Agilent 16750A/B Logic Analyzer
Characteristics
The characteristics are not specifications, but are included as
additional information.
