185
Chapter 3: Reference
Error Messages
particularly useful when you use store qualifiers to store "no states" (or
only the states you are interested in) and the branches taken are stored.
• Save the trigger setup, then simplify it to see what part of the sequence
does get captured. When you learn what needs to be changed, you can
recall the original trigger setup and make changes to it.
See Also “To Specify Default Storing” on page 71
“To save a trigger setup” on page 85
Analyzer armed from another module contains
no "Arm in from IMB" event
This warning is displayed when a 16715A and newer analyzer machine
is in the group run arming tree, armed from another module (not
directly from the group run), and no sequencer event list in the
analyzer contains an "Arm in from IMB" event or no level in a "Wait for
arm in" trigger function.
In this case the analyzer will not wait for the module above it to trigger
before it triggers.
