Chapter 2: Task Guide
Using Symbols
To create a readers.ini file
You can change how an ELF/Stabs, Ticoff or Coff/Stabs symbol file is
processed by creating a reader.ini file.
1. Create the reader.ini file on your workstation or PC.
2. Copy the file to /logic/symbols/readers.ini on the logic analysis system.
Reader options C++Demangle
1= Turn on C++ Demangling (Default)
0= Turn off C++ Demangling
C++DemOptions
803= Standard Demangling
203= GNU Demangling (Default Elf/Stabs)
403= Lucid Demangling
800= Standard Demangling without function parameters
200= GNU Demangling without function parameters
400= Lucid Demangling without function parameters
MaxSymbolWidth
80= Column width max of a function or variable symbol
Wider symbols names will be truncated.
(Default 80 columns)
OutSectionSymbolValid
0= Symbols whose addresses aren't within the
defined sections are invalid (Default)
1= Symbols whose addresses aren't within the
defined sections are valid
This option must be specified in the Nsr section of the Readers.ini file:
[Nsr]
OutSectionSymbolValid=1
ReadElfSection
2= Process all globals from ELF section (Default)
Get size information of local variables
1= Get size information of global and local variables
Symbols for functions will not be read, and
only supplemental information for those symbols in
the Dwarf or stabs section will be read.
0= Do not read the Elf Section
If a file only has an ELF section this will have no effect and the ELF
