U2121A-101 Operating Guide 21
Product Characteristics and Specifications
Ta ble 8 General characteristics of the U2121A-101 RF switch driver board
General Characteristics
Power consumption • +24 VDC, 2.5 A
• Isolated ELV supply source
Operating environment 0 °C to 40 °C
Storage temperature –40 °C to 70 °C
Operating humidity Up to 85% at 40 °C (non-condensing)
Storage humidity 5% to 90% RH (non-condensing)
EMC • IEC61326-2002/EN61326:1997+A1:1998+A2:2001+A3:2003
• Canada: ICES-001:2004
• Australia/New Zealand: AS/NZS CISPR11:2004
Safety IEC 61010-1:2001/EN 61010-1:2001 (2nd edition)
Driving current per channel 300 mA (max)
Total current 1500 mA (max)
IO channels for RF switch 5 channels
Generic IO 3 digital inputs and 3 digital outputs
Board dimension (W x D) 150 mm x 72 mm
Casing dimension (W x D x H) 153 mm x 85 mm x 38 mm
Weight • With casing: 146 g
• Without casing: 86 g
Warranty One year
