Specifications
Introduction
5-2 Agilent E4418B User’s Guide
Introduction
This chapter details the power meter’s specifications and supplemental
characteristics.
Specifications describe the warranted performance and apply after a 30
minute warm-up. These specifications are valid over the power meter’s
operating and environmental range unless otherwise stated and after
performing a zero and calibration.
Supplemental characteristics, which are shown in italics, are intended to
provide information useful in applying the power meter by giving typical,
but nonwarranted performance parameters. These characteristics are
shown in italics or denoted as “typical”, “nominal” or “approximate”.
For information on measurement uncertainty calculations, refer to Agilent
Application Note 64-1A, “Fundamentals of RF and Microwave Power
Measurements”, Literature Number 5965-6630.
