Menu Reference
Front Panel Menu Reference "System/Inputs" Menu
Agilent E4418B User’s Guide 3-33
This softkey also accesses the Battery menu which allows you
to set the display backlight to On, Off, or Timed mode. In
Timed mode, the backlight turns off 10 minutes after the last
key press. To turn the backlight on again, press any key. While
operating with ac power connected these keys are grayed out
and the backlight is permanently on. On instrument preset
the Backlight is set to “On”
◆
Press this softkey to turn the display backlight permanently
On.
◆
Press this softkey to set the display backlight to be Off while
the power meter is operating under battery power.
◆
Press this softkey to select the Backlight Timed mode. When
the power meter is in this mode and is operating under
battery power, the display backlight turns off 10 minutes
after the last key press. To turn the backlight back on, press
any key.
◆
Pressing this softkey returns the display to the previous
screen.
Backlight On
Backlight Off
Backlight Timed
Done
