Menu Reference
Front Panel Menu Reference "System/Inputs" Menu
Agilent E4418B User’s Guide 3-29
•
Press this softkey to access a menu which allows you to modify the
setup of the recorder output. Refer to “Recorder Output”, on
page 2-59 for further information.
■
Press this softkey to switch the rear panel Recorder Output on
or off. The Recorder Output produces a dc voltage that
corresponds to the selected input channel power level in
Watts.
■
Press this softkey to enter the input power level that you want
to represent the 1 V
dc
maximum output voltage of the
Recorder Output.
■
Press this softkey to enter the input power level that you want
to represent the 0 V
dc
minimum output voltage of the
Recorder Output.
•
Press this softkey to access a menu which allows you to test and
service your power meter.
■
Press this softkey to access the power meter’s self test menu.
◆
Press this softkey to run a series of tests on the power meter.
Refer to “Instrument Self Test”, on page 2-68 for further
information on the tests run.
◆
Press this softkey to verify that the power meter makes an
accurate measurement of it’s 1 mW POWER REF output.
◆
Press this softkey to access a menu which allows you to
select individual self tests to be run.
❖
Press this softkey to perform a ROM checksum verification
test, verify the memory and that the correct amount of
RAM is present.
Recorder Output
Output Off On
Max Power
Min Power
Service
Self Test
Instrument Self Test
Confidence Check
Individual
Memory
HP4402.book Page 29 Wednesday, November 29, 2000 4:46 PM
