Menu Reference
Front Panel Menu Reference "Meas/Setup" Menu
Agilent E4418B User’s Guide 3-17
◆
Press this softkey to select whether the TTL output reflects
an overlimit condition, under limit condition or both.
◆
Press this softkey to select whether a high or low level TTL
Output represents a limits failure.
Limits OVER UNDER EITHER
Fail O/P HIGH LOW
