Using the Oscilloscope
To perform basic user interface operations
3-31
Figure 3-19
Dialog Box Interface Elements
Click to put a check mark
in the check box and
enable Connect Dots
mode
Click one of these
check boxes to select
Color Grade or Infinite
persistence
Click and drag the
Intensity control
slider up to increase
the intensity of the
grid
Click and drag the
Intensity control
slider down to
decrease the
intensity of the grid
Click and drag the
title bar to move the
dialog box on the
screen
Click one of these
Close buttons to
close the dialog box
Click and drag the
Intensity control
slider up to increase
the waveform
brightness
Click and drag the
Intensity control
slider down to
decrease the
waveform brightness
click one of these
radio buttons to
change the number
of waveform
viewing areas
Click this check box to
enable the touch screen
