User`s guide

Setting Up the Oscilloscope
To inspect options and accessories
1-8
Some accessories that will enhance your work with the 8000A series
oscilloscopes are listed in table 1-2.
Table 1-2
Accessories for the 8000A Series Infiniium Oscilloscopes
Agilent Model
Number
Description
10070C 20 MHz, 1:1, 1 M
Ω Passive Probe
10073C 500 MHz, 10:1, 2.2 M
Ω Passive Probe
10076A 4 kV, 250 MHz High Voltage Probe
N2771A 10 kV, 50 MHz High Voltage Probe
10833A GPIB cable, 1 m
10833B GPIB cable, 2 m
10833C GPIB cable, 4 m
10833D GPIB cable, 0.5 m
E2609B Rackmount Kit
1184A Testmobile with keyboard and mouse tray, accessories draw
N2766A PC Board Mini-Probe Socket (horizontal mount, quantity 25)
22768A PC Board Mini-Probe Socket (vertical mount, quantity 25)
10073C 500 MHz, 10:1, 2.2 M
Ω Passive Probe
1146A AC/DC Current Probe 100 kHz
1147A AC/DC Current Probe 50 MHz
1130A 1.5 GHz InfiniiMax Probe Amplifier
E2675A InfiniiMax Differential Browser Probe Head
1153A 200 MHz Differential Active Probe
1155A 750 MHz 2-Channel, Low-Mass Single-ended Active Probe
1156A 1.5 GHz Single-ended Active Probe
1159A 1 GHz Differential Probe
1162A 25 MHz, 1:1, 1 M
Ω Passive Probe
1163A 1.5 GHz, 10:1, 50
Ω Passive Probe
1165A 500 MHz, 10:1, 10 M
Ω Passive Probe
1171A 500 MHz, 10:1, 10 M
Ω Low-mass Passive Probe
1250-1454 BNC to Miniature Probe Adapter
10467-68701 4 IC Clips, 0.5 mm
