Replacing Assemblies
Use the procedures in this chapter when removing and replacing assemblies and parts
in the Agilent Technologies 8000 Series oscilloscope.
In general, the procedures that follow are placed in the order to be used to remove a
particular assembly. The procedures listed first are for assemblies that must be removed
first.
The graphics in this chapter are representative of the oscilloscope at the time of this
printing. Your unit may look different.
ESD Precautions
When using any of the procedures in this chapter, you must use proper ESD precautions
to protect the oscilloscope components from ESD damage. Failure to follow proper ESD
control procedures may cause immediate failure or latent damage. Latent damage may
result in equipment failure after a period of time. As a minimum, you should place the
oscilloscope on a properly grounded ESD mat and wear a properly grounded ESD wrist
strap when working on the oscilloscope.
CAUTION AVOID DAMAGE TO THE OSCILLOSCOPE!
Failure to implement proper antistatic measures may result in damage to the oscilloscope.
Tools Required
The following tools are required for these procedures.
• Torx drivers: T6, T8, T10, T15, T20
• Socket wrench: 5/8 inch
• Medium size (3/16-in) flat-blade screwdriver
• Nut Drivers: 3/16-in, 9/32-in, 5/16-in, 5/8-in
• Torque driver, 0.34 Nm (3 in-lb), 5 mm or 3/16-in hex drive
• Torque driver, 0.34 Nm (3 in-lb), Torx T6 drive
CAUTION REMOVE POWER BEFORE REMOVING OR REPLACING ASSEMBLIES!
Do not remove or replace any circuit board assemblies in this oscilloscope while power is applied.
The assemblies contain components which may be damaged if the assembly is removed or
replaced while power is connected to the oscilloscope.
WARNING SHOCK HAZARD!
To avoid electrical shock, adhere closely to the following procedures. Also, after disconnecting
the power cable, wait at least three minutes for the capacitors on the power supply to discharge
before servicing this oscilloscope. Hazardous voltages exist on the inverter for the display monitor
while power is applied.
