Specifications

Contents
7
1 General Information
Instruments covered by this service guide 11
To determine whether the oscilloscope is under warranty 12
Accessories supplied 13
Accessories available 14
Options available 15
Specifications & characteristics 16
Environmental Conditions 17
Measurement Category 17
Oscilloscope Dimensions 18
2 Preparing for Use
To inspect package contents 20
To connect power 22
To connect the mouse, keyboard, LAN, printer, and GPIB cable 24
To connect the standard 10073C probes 25
To connect optional InfiniiMax oscilloscope probes 26
To connect the digital probe 28
Digital probe lead set 29
To tilt the oscilloscope upward for easier viewing 31
To turn on the oscilloscope 32
To turn off the oscilloscope 32
To verify basic oscilloscope operation 33
Installing application programs on Infiniium 34
Changing Windows System Settings 34
To clean the oscilloscope 35
3 Testing Performance
To test the DC calibrator 40
To test input resistance 42
To test single cursor voltage measurement accuracy with offset 43
To test bandwidth 47
To verify threshold accuracy 49
To test time scale accuracy 59
To test delta time measurement accuracy 61
Performance Test Record 64
4 Calibrating and Adjusting
To run the self calibration 69
5 Troubleshooting
To install the fan safety shield 73
To troubleshoot the oscilloscope 74
Primary Trouble Isolation 76
!
