Chapter 3: Testing Performance
Performance Test Record
65
Single Cursor
Voltage
Measurement
Accuracy with
Offset
Range Supply Limits
Channel 1 Channel 2 Channel 3 Channel 4
5 V/div 35 V 33.48 V to 36.52 V ___________ ___________ ___________ ___________
2 V/div 14 V 13.39 V to 14.61 V ___________ ___________ ___________ ___________
1.25 V/div 8.75 V 8.17 V to 9.33 V ___________ ___________ ___________ ___________
500 mV 3.5 V 3.35 V to 3.65 V ___________ ___________ ___________ ___________
250 mV 1750 mV 1.61 V to 1.89 V ___________ ___________ ___________ ___________
100 mV 700 mV 669 mV to 731 mV ___________ ___________ ___________ ___________
50 mV 350 mV 334 mV to 366 mV ___________ ___________ ___________ ___________
20 mV 140 mV 133 mV to 147 mV ___________ ___________ ___________ ___________
10 mV 70 mV 66.0 mV to 74.0 mV ___________ ___________ ___________ ___________
5 mV 35 mV 32.5 mV to 37.5 mV ___________ ___________ ___________ ___________
Bandwidth Down from reference: Channel 1 Channel 2 Channel 3 Channel 4
Equivalent Time
MSO/DSO8064A
MSO/DSO8104A
<3.0 dB at 600 MHz
<3.0 dB at 1 GHz
___________
___________
___________
___________
___________
___________
___________
___________
Real Time
MSO/DSO8064A
MSO/DSO8104A
<3.0 dB at 600 MHz
<3.0 dB at 1 GHz
___________
___________
___________
___________
___________
___________
___________
___________
Digital Channels
Threshold
Accuracy
(MSO models
only)
±100 mV +3% of threshold setting
High-to-Low Transitions
Threshold Voltage Limits Results
5 V 4.750 V to 5.25 V _____________
0 V -100 mV to 100 mV _____________
-5 V -5.25 V to -4.75 V _____________
Low-to-High Transitions
Threshold Voltage Limits
5 V 4.750 V to 5.25 V _____________
0 V -100 mV to 100 mV _____________
-5 V -5.25 V to -4.75 V _____________
Test Limits Results
