Chapter 2: Preparing for Use
Installing application programs on Infiniium
34
Installing application programs on Infiniium
Infiniium is an open Windows system. This allows you to install your own application software.
Agilent has verified that the following applications are compatible with the Infiniium oscilloscope
application.
• Agilent Vector Signal Analysis
• Agilent VEE Pro
• Amherst Systems Oscilloscope Tools
• Microsoft Office 2000
• MathWorks MATLAB
• Mathsoft MathCad 2001i
• McAfee VirusScan
• Symantec Norton AntiVirus
If you install an application other than those which Agilent has tested, it is possible that it could
break the oscilloscope application. This would require you to reinstall the oscilloscope
application. Refer to the Infiniium Oscilloscope User’s Quick Start Guide for instructions on
reinstalling the oscilloscope application.
Changing Windows System Settings
There are several Windows System settings that can be changed to suit your own personal
preferences. However, there are some system settings that you should avoid changing because
it will interfere with the proper operation of the oscilloscope.
• Do not change the Power Options.
• Do not change the System Properties Hardware Tab settings.
• Do not change the System Properties Advanced Tab settings.
• Do not change the Regional and Language Options Advanced Tab settings.
• Do not remove Fonts.
• Display Settings
• Do not change or turn off the default screen saver. The screen saver turns off the display’s
backlights, extending their life.
• Do not change the screen resolution or the color quality using the Control Panel Display
Settings. You may modify display settings by double-clicking the Intel Graphics Media
Accelerator Driver icon in the System tray.
• Do not modify the Advanced settings.
• Do not use the Administrative Tools to enable or disable Internet Information Services
(Web Server). Use the Infiniium Web Control dialog box to enable or disable the Web
Server.
Before installing any software, you should exit the oscilloscope application.
Before changing any Windows System settings outside of the oscilloscope
application you should Exit the oscilloscope application.
