Specifications
Table Of Contents
- General Information
- Preparing for Use
- To inspect package contents
- To connect power
- To connect the mouse, keyboard, LAN, printer, and GPIB cable
- To connect the standard 10073C probes
- To connect optional InfiniiMax oscilloscope probes
- To connect the digital probe
- Digital probe lead set
- To tilt the oscilloscope upward for easier viewing
- To turn on the oscilloscope
- To turn off the oscilloscope
- To verify basic oscilloscope operation
- Installing application programs on Infiniium
- Changing Windows System Settings
- To clean the oscilloscope
- Testing Performance
- Calibrating and Adjusting
- Troubleshooting
- To install the fan safety shield
- To troubleshoot the oscilloscope
- Primary Trouble Isolation
- No Display Trouble Isolation
- To check the backlight inverter voltages
- To check the display board video signals
- Power Supply Trouble Isolation
- To check probe power outputs
- To Check the keyboard
- To check the LEDs
- To check the motherboard, CPU, and RAM
- To setup the BIOS
- To troubleshoot the acquisition system
- Software Revisions
- Replacing Assemblies
- To return the oscilloscope to Agilent Technologies for service
- To remove and replace the top cover
- To remove and replace the bottom sleeve
- To disconnect and connect Mylar flex cables
- To remove and replace the CD-ROM drive
- To remove and replace the AutoProbe assembly
- To remove and replace the internal digital input cable (MSO models only)
- To remove and replace the backlight inverter board
- To remove and replace the front panel assembly
- To remove and replace the keyboard, touch screen, and flat-panel display assemblies
- To remove and replace the acquisition board assembly
- To remove and replace the PCI bridge board
- To remove and replace the display board
- To remove and replace the hard disk drive
- To remove and replace the motherboard
- To replace the Intel motherboard with the ADLINK motherboard
- To remove and replace the power supply
- To remove and replace the fan controller board
- To remove and replace a fan
- To remove and replace the probe power and control assembly
- Replaceable Parts
- Theory of Operation
- Index
Chapter 1: General Information
Options available
15
Options available
The following options are available for the Infiniium oscilloscope. Other options may be available.
See your Agilent Technologies Sales Representative or visit www.agilent.com and perform a
search for your oscilloscope’s model number.
Table 1-2
8000 Series Oscilloscope Options
Calibration Option
A6J ANSI Z540-Compliant Calibration
Factory-Installed
Instrument Options
040 Increase acquisition memory to 8 M on half channel and 4 M on all channels
080 Increase acquisition memory to 16 M on half channel and 8 M on all channels.
160 Increase acquisition memory to 32 M on half channel and 16 M on all channels.
320 Increase acquisition memory to 64 M on half channel and 32 M on all channels.
640 Increase acquisition memory to 128 M on half channel and 64 M on all channels.
Note: Memory options are also available after oscilloscope purchase. See the "Customer-Installed Instrument
Options" heading in this table.
002 EZJIT Jitter Analysis Software
003 High-Speed Serial Data Analysis Software with Clock Recovery
006 My Infiniium Integration Package
007 Low-Speed Serial Data Analysis Software for I2C and SPI
008 CAN Serial Data Analysis Software
009 InfiniiScan Event Identification Software
017
≥40 GB Removable Hard Disk Drive. Available on new oscilloscope purchase only.
Replaces ≥40 GB internal hard disk drive with a ≥40 GB removable hard disk drive.
Order the N5422A for additional hard disk drive cartridges that contain the full
Windows operating system and oscilloscope application.
Customer-Installed
Instrument Options
N5407A-040 Increase acquisition memory to 8 M on half channel and 4 M on all channels
N5407A-080 Increase acquisition memory to 16 M on half channel and 8 M on all channels.
N5407A-160 Increase acquisition memory to 32 M on half channel and 16 M on all channels.
N5407A-320 Increase acquisition memory to 64 M on half channel and 32 M on all channels.
N5407A-640 Increase acquisition memory to 128 M on half channel and 64 M on all channels.
Note: Memory options installed after oscilloscope purchase do not require opening the oscilloscope case.
E2681A EZJIT Jitter Analysis Software
N5384A High-Speed Serial Data Analysis Software with Clock Recovery
E2699A My Infiniium Integration Package
N5391A Low-Speed Serial Data Analysis Software for I2C and SPI
