Chapter 7: Replaceable Parts
Replaceable Parts List
148
W4 D8064-61601 1 POWER HARNESS CABLE
W5 54810-61617 1 POWER INPUT/LINE SINC
W6 54810-61613 1 CABLE ASSEMBLY POWER SUPPLY
W7 54855-61624 1 MOTHERBOARD SWITCH CABLE
W8 54810-61606 1 AUTOPROBE INTERFACE CABLE
W11 54857-61613 1 DISPLAY CABLE
W12 54826-61601 1 KEYBOARD CABLE
W13 D8104-61603 2 SERIAL ATA CABLE (NOT ON OPTION 017)
W14 54810-61615 1 HARD DRIVE GROUND CABLE (NOT ON OPTION 017)
W17 54810-61604 1 PROBE POWER CABLE
W19 54855-61606 1 FAN CABLE
W20 54801-61626 1 KEYBOARD INTERCONNECT
W21 D8104-61605 1 BACKLIGHT POWER CABLE
W23 54801-61638 2 SMB CABLE BNC TTL & EXT. TRIGGER
W24 54826-61604 1 INTERNAL DIGITAL INPUT CABLE (MSO models)
W25 D8104-61602 1 FRONT PANEL USB CABLE
W26 D8104-61604 1 TOUCHSCREEN CABLE
W27 54857-61613 1 FLAT-PANEL DISPLAY DRIVER CABLE
Replaceable Parts
Ref.
Des.
Agilent Part
Number Qty Description
