Chapter 7: Replaceable Parts
Replaceable Parts List
145
Replaceable Parts List
The following table is a list of replaceable parts and is organized as follows:
• Exchange assemblies in alphanumeric order by reference designation.
• External chassis parts in alphanumeric order by reference designation. These parts are
generally those that take the physical wear and tear of use.
• Internal parts in several categories. Each category is in alphanumeric order by reference
designation. Replacing these parts generally requires opening the cabinet.
The information given for each part consists of the following:
• Reference designation.
• Agilent Technologies part number.
• Total quantity (Qty) in an oscilloscope or on an assembly. The total quantity is given once and
at the first appearance of the part number in the list.
• Description of the part.
Replaceable Parts
Ref.
Des.
Agilent Part
Number Qty Description
Exchange Assemblies
A1 54831-66523 1 4-CH ACQUISITION ASSEMBLY (DSO8064A)
A1 54832-66523 1 4-CH ACQUISITION ASSEMBLY (DSO8104A)
A1 54831-66524 1 4-CH ACQUISITION ASSEMBLY (MSO8064A)
A1 54832-66524 1 4-CH ACQUISITION ASSEMBLY (MSO8104A)
External Chassis Parts
MP13 54801-47403 1 KNOB 24 MM GRAY
MP14 54801-47408 1 KNOB 18 MM YELLOW
MP15 54801-47404 1 KNOB 12 MM YELLOW
MP16 54801-47409 1 KNOB 18 MM GREEN
MP17 54801-47405 1 KNOB 12 MM GREEN
MP18 54801-47410 1 KNOB 18 MM PURPLE
MP19 54801-47406 1 KNOB 12 MM PURPLE
MP 20 54801-47411 1 KNOB 18 MM PINK
MP21 54801-47407 1 KNOB 12 MM PINK
MP22 54801-47401 4 KNOB 12 MM GRAY
MP26 54832-94330 1 FRONT PANEL 4-CH LABEL (DSO models)
MP26 54838-94330 1 FRONT PANEL 4-CH LABEL (MSO models)
MP28 D8064-94301 1 LOGO LABEL (DSO8064A)
MP28 D8104-94301 1 LOGO LABEL (DSO8104A)
MP28 M8064-94301 1 LOGO LABEL (MSO8064A)
MP28 M8104-94301 1 LOGO LABEL (MSO8104A)
MP31 54810-68701 1 ACCESSORY POUCH
NOT SHOWN
54810-42201 1 FRONT PANEL COVER
MP32 5042-1798 2 REAR FEET
MP34 54810-44901 1 MOLD OVER HANDLE
MP35 54810-45001 2 END CAP HANDLE
MP36 54810-61001 4 BOTTOM FEET w/INSERT
MP37 54810-03702 1 TILT STAND
MP38 01680-41002 4 SIDE FOOT
MP43 D8104-94302 1 USB LABEL
W18 8120-1521 1 CABLE-POWER (standard 125V USA)
