Chapter 1: General Information
Accessories available
14
Accessories available
The following accessories are available for use with the Agilent Technologies Infiniium
oscilloscope. Other accessories may be available. See your Agilent Technologies Sales
Representative or visit www.agilent.com.
Table 1-1
8000 Series Oscilloscope Accessories
1130A 1.5 GHz InfiniiMax Differential and Single-Ended Probe Amplifier
E2669A InfiniiMax Connectivity Kit for Differential and Single-Ended Measurements
E2668A InfiniiMax Connectivity Kit for Single-Ended Measurements
E2675A InfiniiMax Differential Browser Probe Head
E2676A InfiniiMax Single-Ended Browser Probe Head
E2677A InfiniiMax Differential Solder-in Probe Head
E2678A InfiniiMax Differential and Single-Ended Socketed Probe Head
E2679A InfiniiMax Single-Ended Solder-in Probe Head
E2695A InfiniiMax Differential SMA Probe Head
1144A 800 MHz Active Probe
Requires 1142A power supply
1145A 750 MHz 2-Channel, Low-Mass Active Probe
Requires 1142A power supply
01144-61604 1:2 Probe Power Fan-Out
To provide power for two 1144A or 1145A probes
1146A 10 kHz, 100 A AC/DC Current Probe
1147A 50 MHz, 50 A AC/DC Current Probe
1153A 200 MHz Differential Probe
1155A 750 MHz 2-Channel, Low-Mass Active Probe
1156A 1.5 GHz Active Probe
10070C 1:1 1 M
Ω Passive Probe
10073C 10:1 2.2 M
Ω Passive Probe
1162A 1:1 1 M
Ω Passive Probe
1163A 10:1 500
Ω, Low-C Resistive Divider Passive Probe
1165A 10:1 10 M
Ω Passive Probe
1171A Low-Mass, Miniature 10:1 10 M
Ω Passive Probe
10833A GPIB cable, 1 m
10833B GPIB cable, 2 m
10833C GPIB cable, 4 m
10833D GPIB cable, 0.5 m
54006A 6 GHz, 10:1 500 Ω or 20:1 1 kΩ Resistor Divider Probe
E2609B Rackmount Kit
1184A Testmobile with accessory drawer and tray for mouse/keyboard
