76 Agilent E5505A User’s Guide
4
Expanding Your Measurement Experience
Making the measurement
1
Click the Continue button when you have completed the beatnote check
and are ready to make the measurement.
2
When the PLL Suppression Curve dialog box appears, check View Measured
Loop Suppression, View Smoothed Loop Suppression, and View Adjusted
Loop Suppression in the lower right of the dialog box.
See Figure 45 on page 77.
Figure 44 Oscilloscope display of beatnote from test set monitor port
0
V
-1V/div
E5505a_oscillo_disp_beatnote
25 Feb 04 rev 1
