Expanding Your Measurement Experience
4
Agilent E5505A User’s Guide 73
:
Table 6 Test set signal input limits and characteristics
Limits
Frequency 50 kHz to 26.5 GHz
Maximum Signal Input Power +30 dBm (with Option 001)
At Attenuator Output, Operating Level Range:
•
RF Phase Detectors
•
Microwave Phase Detectors
•
Internal AM Detector
0 to +23 dBm
0 to +5 dBm
0 to +20 dBm
Downconverters:
•
N5502A/70422A
•
N5507A/70427A
+5 to +15 dBm
0 to +30 dBm
Characteristics
Input Impedance 50 Ω nominal
AM Noise DC coupled to 50 Ω load
NOTE
Refer to the following system connect diagram examples in Chapter 18, “System
Interconnections” for more information about system interconnections.
•
Figure 307, “E5505A system connections with standard test set,” on page 403
•
Figure 308, “E5505A system connections with test set option 001,” on page 404
•
Figure 309, “E5505A system connections with test set option 201,” on page 405
