- Safety and Regulatory Information
469
Agilent Technologies
A
Service, Support, and Safety
Information
Safety and Regulatory Information 470
Service and Support 476
Return Procedure 477
This appendix provides safety and regulatory information,
which you should review prior to working with your Agilent
system. The information contained in it applies to all
Agilent-supplied instruments in the system, and the system as a
whole.
It also contains information on servicing and obtaining support
for an Agilent system or instrument, including procedures for
removing an instrument from a system, returning it to Agilent,
and re-installing it.
