Preventive Maintenance
21
Agilent E5505A User’s Guide 465
Benchtop Instrument
Figure 339 Instrument lock links, front and rear
Inst_lock_links
24 Feb 04 rev 1
Front links
Rear links
To remove an instrument from a benchtop system
1 Power off each instrument in the system.
•
For details, see “Powering the System Off" on
page 45.
2 Unplug the selected instrument’s power
cord from the AC power supply.
3 Remove the power cord and other cables
from the front and rear of the instrument.
•
Note the location of cables for re-installation.
