458 Agilent E5505A User’s Guide
21
Preventive Maintenance
SMA Connector Precautions
Use caution when mating SMA connectors to any precision 3.5 mm RF
connector. SMA connectors are not precision devices and are often out of
mechanical tolerances, even when new. An out-of-tolerance SMA connector
can ruin a 3.5 mm connector on the first mating. If in doubt, gauge the SMA
connector before connecting it. The SMA center conductor must never extend
beyond the mating plane.
Cleaning Procedure
1
Blow particulate matter from connectors using an environmentally-safe
aerosol such as Aero-Duster. (This product is recommended by the United
States Environmental Protection Agency and contains tetrafluoroethane.
You can order this aerosol from Agilent (see Table 76).)
2
Use alcohol and a lint-free cloth to wipe connector surfaces. Wet a small
swab with a small quantity of alcohol and clean the connector with the
swab.
3
Allow the alcohol to evaporate off of the connector before making
connections.
CAUTION
Do not allow excessive alcohol to run into the connector. Excessive alcohol
entering the connector collects in pockets in the connector’s internal parts. The
liquid will cause random changes in the connector’s electrical performance. If
excessive alcohol gets into a connector, lay it aside to allow the alcohol to
evaporate. This may take up to three days. If you attach that connector to another
device it can take much longer for trapped alcohol to evaporate.
